Further to this mornings #tetrapod #tetrapods toot I've done a very quick n dirty @FreeCAD tutorial video on how to #CAD model one up... erm as an aside tetrapod people what do we call each limb of a tetrapod? Leg? Arm? Tooth? Who knows! Anyhoo here is the video on my @MakerTube
https://makertube.net/w/pydrT4Wued1XuMHk3qXdj7

I blame @grajohnt for introducing me to people making #tetrapods and then seeing them all over the #why25 feeds... so naturally started my working week working out a @FreeCAD approach to laying one out! Might do a quick video later. #CAD #FreeCAD

Forged in FreeCAD: CERN CMS Detector Cable Clamps
In case it passed you by, over on our mastodon account and on the X platform we have run the hashtag #FreeCADFriday for a long time. It's a straightforward "show everyone what you are up to with FreeCAD" type affair and every week so many amazing projects show up as responses.
#CERN #FreeCAD #CAD #CMS #Muons
https://blog.freecad.org/2025/08/11/forged-in-freecad-cern-cms-detector-cable-clamps/
#UserStory

#FreeCadFriday This has been my first full week using FreeCAD. I've made so many mistakes, so many retries, but also some progress!

I'm working on a model of the Zeppelin-like airship from one of my novels - I hope eventually to import it into a program that will let me walk through it.

Having some trouble getting rotation joints to stick, but here's a screenshot of one of the engine nacelles.

Happy #FreeCADFriday everyone! Hope you all have a grand weekend. Show us what you've been up too with #FreeCAD. #CAD #CAM #BIM

FreeCAD 1.0.2 released
We’ve just released a new update with over 30 bugfixes and small improvements, go get it here. As a reminder, these 1.0.X releases bring added stability to version 1.0 of FreeCAD, whereas new features in development will be released in version 1.1.
#opensource #CAD #FreeCAD

https://blog.freecad.org/2025/08/06/freecad-1-0-2-released/
#Releases

WOOHOO, fixed my #3DPrinting woes! Now testing a clip for this wireless mic; it'll sit around my neck (to not compete w/ mask straps, Shokz headphones, & glasses).

I'm tired of wearing out my voice at events, pushing my mumbles through an N95 for hours every day. So I'm upgrading a mic/speaker combo designed for teachers & tour guides.

More info: https://alexglow.notion.site/Mask-augmentations-2475bc4fe798802e9a6ec9bcc7e0ec63

// #OnShape #CAD #WearableTech

I've tried using the Gridfinity addon for #FreeCAD recently, and it's super useful! However, I have a small problem in that the tolerances are so tight that I have to really force the resulting prints into the base plates.

Is there some setting I can adjust in the addon to make the tolerances a bit looser?

Good news for #CAD software users, #FreeCAD (1.0.1) is now in the #OpenBSD -current ports tree. ​

A huge effort by Johannes Thyssen Tishman (jtt@) and other porters getting this committed.

jtt@ modified ports/cad/freecad/*: Import cad/freecad

ok jca@ and rsadowski@

FreeCAD is an open-source parametric 3D modeler made primarily to design real-life objects of any size. Parametric modeling allows you to easily modify your design by going back into your model history and changing its parameters.

Context: https://marc.info/?l=openbsd-ports&m=175414002928343&w=2

A bit of #FreeCADFriday to add a couple of screws to fasten the two halves of the audio-level-shifter case (because my initial friction-fit pegs didn't handle the vibration of being mounted on a bike very well)

Just checking over clearances before sticking it on the 3D printer

Performance of Major Currencies vs GBP for July 2025. View live exchange rates at https://moneydero.com/markets #GBP #USD #EUR #JPY #CHF #CAD #AUD

It's #FreeCADFriday! Help us celebrate all things #FreeCAD and show us what projects you are working on! #CAD #CAM #BIM

Tutorial: Using the Additive Pipe Tool
The additive pipe tool is an excellent tool that allows a sketch or sketches to be swept along a series of edges to create a solid pipe with the profile of the original sketch. #FreeCAD #CAD #CAM #BIM
https://blog.freecad.org/2025/07/31/tutorial-using-the-additive-pipe-tool/
#Tutorials

Imho #Rhino is the most weird #3D modeling software I ever saw.

Is anybody here using it?

#CAD #Rhino3D

https://www.rhino3d.com

My apartment in Spain has no door locks. This seems common?? I got tired of the kids interrupting so whipped up this lock:

A small @FreeCAD video over on my shiny new @MakerTube account. This, the first of a few #FreeCAD tutorials is a slight outlier... we take a little look at a few issues that new users might have when trying to follow tutorials! #FreeCADFriday #CAD #Opensource #Learning
https://makertube.net/w/sjbmtxD3CbtcBk3pmYvQPJ

FreeCAD at FAB25
Between July 4th and 11th split between Brno and Prague, FAB25, the latest iteration of the annual Fab Lab travelling conference, took place. Excellently we had representation from the FreeCAD community speaking at the event.
#CAD #FreeCAD #fablab #FAB25
https://blog.freecad.org/2025/07/18/freecad-at-fab25/
#Events

Planning out the front panel and #pcb edge cuts for another #electronics summer project, realizing how insanely good #opensource #cad tools @qcad #qcad pro and @FreeCAD #freecad have become

Hi. I'm kbob. Intro time.

I used to get paid to write software. Now that I'm retired, I do it for free. I also play with 3D printers and electronics and stuff.

I love learning, and I like to make things the hard way. I often create a #BuildThread about a project and update it for months.

Interests

#3DPrinting
#CAD
#electronics
#FPGA
#synth
#BassGuitar
#solar
#geothermal
#homelab
#homeassistant
#pinball
#ev
#ebike
#biking
... and more
